Are 24 volts better than 12 volts?

1.6K



Today, let’s delve into the world of 24-volt solar power systems and explore the advantages of opting for a higher voltage battery bank. We’ll also shed light on the rationale behind this choice, as well as the pros and cons associated with utilizing a higher voltage configuration for your off-grid solar power system.

So, why consider 24 volts over 12 volts?

To begin with, it’s a cost-effective choice. When constructing off-grid solar power setups, 24-volt systems consistently offer savings. This is primarily due to the cost of wiring in your system, which can add up, especially for larger installations. In a 12-volt system, the current passing through the wires is doubled compared to a 24-volt system. Consequently, thicker wires are required to accommodate this higher load, and copper wiring can be quite expensive.

The solar charge controller plays a pivotal role in your system’s cost-effectiveness. It’s rated in amps, and here’s the key: if you’re operating a 24-volt system, a solar charge controller half the size of what you’d use for a 12-volt system suffices. Many of these controllers are versatile, designed to handle both 12 and 24-volt setups. For instance, with a 20-amp controller on a 12-volt system, you’re limited to connecting just 260 watts of solar power.

Another compelling advantage is that most components thrive at higher voltages. When you have high-voltage solar panels and a battery bank operating at a higher voltage, your solar charge controller’s workload diminishes. Consequently, this leads to a marginal boost in efficiency when most components operate at an elevated voltage.

Moreover, you’ll experience less energy loss through your wires. As power courses through them, wires tend to heat up, resulting in losses. However, when you’re running at a higher voltage, these losses are notably reduced.

Now, let’s consider some drawbacks:

Firstly, your solar panel array must produce a voltage higher than your battery bank’s voltage. This means 12-volt solar panels won’t work with a 24-volt system. You’ll need 60-volt or 100-volt solar panels, which can be series-connected as long as your solar charge controller can handle it.

Secondly, using a 24-volt system means you can’t employ 12-volt appliances without a converter. This adds to the system’s cost, albeit not substantially. A converter, typically priced around $30 to $40, is recommended with overcurrent protection and safety features like temperature control. However, it’s worth noting that despite this added expense, 24-volt systems still offer significant cost savings, particularly when it comes to components like solar charge controllers, where you can save anywhere from $100 to $400.

Continuing with the disadvantages, finding 24-volt equipment locally can be challenging. If you’re purchasing everything online, this isn’t a concern, as 24-volt components are readily available. However, if you prefer local sourcing, 12 volts might be the more convenient option.

Consider this scenario:

you walk into a local store seeking an inverter and a deep-cycle battery. While it’s possible, it’s not the most efficient route, as the energy output from an alternator in a 12-volt system falls significantly short of what a 24-volt system can achieve. Despite this inefficiency, some individuals still pursue this approach. If you decide to do so, ensure your alternator is suitable for deep charging, or better yet, consult a shop that specializes in installing extra alternators designed for this purpose for a more effective long-term solution.

Let’s explore the practicalities of running small appliances on 30 to 40 amps.

Moreover, numerous boat alternators are specifically engineered to recharge deeply discharged deep cycle batteries tailored for marine applications. Imagine having one alternator for your vehicle’s charging system and another for a 12, 24, or 48-volt solar battery setup.

In this scenario, it’s a wise choice because your vehicle’s charging system is optimized for charging a battery with a capacity of 100-amp hours, designed to keep the engine running while concurrently powering a couple of small appliances drawing 30 to 40 amps. Charging a solar battery with an alternator, however, should only be done if you have a dedicated alternator for this purpose.

Now, let’s shift our focus to weighing the pros and cons of employing a 12-volt versus a 24-volt battery system. This evaluation will help us determine the most suitable circumstances for employing a 24-volt battery configuration.

For smaller systems, a 12-volt setup suffices, whereas if you’re dealing with a medium-sized system, the logical choice is to opt for 24 volts. In the case of house systems or off-grid cabins, a 48-volt configuration is preferable, although it’s worth noting that 24-volt systems offer a higher level of safety. While a 12-volt system might deliver a jolt if you accidentally touch the battery terminals, a 24-volt system would provide a shock, though still below the 30-volt threshold considered technically safe.

To conclude, it’s crucial to recognize the voltage thresholds where safety becomes a concern

. Beyond 30 volts, sparks can occur, and the risk of electric shock increases. Once you surpass 48 volts, specialized knowledge becomes essential. Conversely, voltages below 24 volts may still produce sparks but pose a lower risk. In summary, opt for 12 volts for small systems, 24 volts for medium-sized setups, and consider 48 volts for cabins or houses with the awareness of increased precautions required at higher voltages.Operating a couple of small appliances typically requires 30 to 40 amps of power.

Moreover, numerous boat alternators are specifically engineered to recharge deeply discharged deep cycle batteries tailored for marine use. If you possess an alternator within your vehicle’s charging system and a separate one for your 12, 24, or 48-volt solar battery, you’re making a prudent choice. Your vehicle’s alternator is primarily designed to charge a battery with a capacity of around 100-amp hours, effectively keeping your engine running while powering a few small appliances with a load of 30 to 40 amps. Charging a solar battery with an alternator is advisable only when it’s a dedicated alternator designed for this purpose.

Now that we’ve weighed the pros and cons of employing a 12-volt versus a 24-volt battery system, let’s pinpoint the optimal scenarios for a 24-volt battery configuration.

For smaller systems, a 12-volt setup suffices. If you’re dealing with a medium-sized system, a 24-volt configuration is advisable. However, if you’re establishing a home system or outfitting an off-grid cabin, a 48-volt system is superior, although it’s crucial to note that 24-volt systems offer enhanced safety. With a 12V system, touching the battery terminals might be unpleasant but generally safe. On the other hand, a 24-volt system can deliver a shock, although it remains below 30 volts, maintaining a technically safe range.

In conclusion,

Once you surpass the 30-volt threshold, the risk of sparking and potential shocks increases significantly. Beyond 48 volts, a deeper understanding of electrical systems becomes imperative. Conversely, dipping below 24 volts may still result in minor sparks but poses relatively less risk. Various online videos serve as cautionary tales of individuals experiencing shocks in less controlled environments. To simplify, opt for 12 volts for small systems, 24 volts for medium-sized RVs or tiny homes, and consider 48 volts for cabins or houses, always prioritizing safety and expertise.
